PRODUCT DESCRIPTION-
The 800.4 EVO 4.0 amplifier comes with exclusive patented * DTR technology.The DTR * is a dynamic thermal recovery system that makes the amplifier always maintain high efficiency by accelerating the thermal exchange of electronic components with the heatsink.
Do you know what that means? An even more reliable and resistant product for you!
* Globally patented technology required by SounDigitalnd is not responsible for the misuse of the product.
TECHNICAL SPECIFICATIONS
- 800.4 EVO 4.0 4Ω
- Power @ 12.6V @ 2Ω: 4 x 200 W RMS
- Power @ 12.6V @ 4Ω: 4 x 132 W RMS
- Power @ 14.4V @ 2Ω: 4 x 223 W RMS
- Power @ 14.4V @ 4Ω : 4 x 147 W RMS
- Bridge Power @ 12.6V @ 4Ω: 2 x 400 W RMS
- THD + N - (10% of rated power): 0.1%
- THD + N - (100% of rated power): 1 %
- Frequency Response: 10Hz - 20kHz
- Crossover: LP / HP: 80Hz 12dB / 8th
- Damping Factor: 200
- Maximum Consumption: 80A
- Dimensions (LxWxH): 14.8 X 11.3 X 5.0 CM
- Weight: 0.66 kg
Package Contents:
- 1 Amplifier Module 800.4 EVO 4.0
- Manual and Warranty Certificate
